Multi Point Metal Spot Welder For Wire Mesh Pets Cage Shelf Supermarket Cart Shopping Rack

Ask Latest Price
Video Channel
Brand Name :TRINTFAR
Model Number :MD-20
Certification :CE
Place of Origin :China
MOQ :1
Price :USD 1000-3000 Set
Payment Terms :L/C, D/A, D/P, D/P, T/T
Supply Ability :500 Per year
Delivery Time :Within 90 days of the final payment
Packaging Details :wooden box
Product Name :Aluminum Plate Welding Machine Medium Frequency Spot Welder
Service Life :8-10 Years
Cooling Water :20-60L/min
Electrode Pressure :1200N-18000N
Maximum short current :10KA-120KA
After-sales Service Provided :Video technical support
Warranty :12 Months
more
Contact Now

Add to Cart

Find Similar Videos
Degree Rotational  Hanging Spot Welder Spot Welding Machine 00:25
Degree Rotational Hanging Spot Welder Spot Welding Machine
Carbon Steel Wire Mesh Spot Welding Machine 2+2MM Stainless Steel Spot Welder 00:45
Carbon Steel Wire Mesh Spot Welding Machine 2+2MM Stainless Steel Spot Welder
High Pressure Lcd Display Automated Resistance Welder 220v Voltage 00:10
High Pressure Lcd Display Automated Resistance Welder 220v Voltage
Middle Frequency DC 40KVA Spot Welding Machines For Copper Terminal Lug Wire 00:34
Middle Frequency DC 40KVA Spot Welding Machines For Copper Terminal Lug Wire
High Efficiency Resistance Spot Welders Welding Area 00:18
High Efficiency Resistance Spot Welders Welding Area
Metal Plate Spot Welding Machine 01:03
Metal Plate Spot Welding Machine
High Speed Automated Welding Machine For Car And Aircraft Applications 00:09
High Speed Automated Welding Machine For Car And Aircraft Applications
Electrical Spot Welder Machines For Thickness 00:13
Electrical Spot Welder Machines For Thickness
High Performance Portable Resistance Welder Electricity Powered 220v / 380v 00:13
High Performance Portable Resistance Welder Electricity Powered 220v / 380v
Water Cooling Advanced Resistance Spot Welders for Welding 00:14
Water Cooling Advanced Resistance Spot Welders for Welding
View Product Description

Multi-Point Spot Welding Machine Wire Mesh Pets Cage Shelf Supermarket Cart Shopping Rack Spot Welding Machine

1. automatic Multi-Point Spot Welding Machine includes two parts: a welding machine and a worktable. The welding machine can be equipped with AC pulse power supply or an energy-saving and environmentally friendly medium frequency inverter DC power supply. Single-head and multi-head long arm spot welding Or raw welding structure, equipped with a welding mold that automatically moves along the XY axis, only need to input the coordinate data of the welding product position, welding power supply and other datas, After the equipment is started, the welding of the product can be completed, and only the manual placement and removal of the workpiece are required;
2.The structure of the equipment is flexible and the combination is convenient. It can be matched with different welding equipment;
3.A programmable manipulator control system is adopted, high-end atmosphere, automatic welding and manual welding can be freely switched, can be taught, find points according to the actual products, high precision and accuracy;
4.Configure the control box to switch different welding specifications. For different welding workpieces, different parameters such as output current and welding time can be set, and one-key switching can be performed during welding;
6.Manufactured in accordance with international ISO Standard and European CE Certificate.

Specification
Item
Model
Maximum Short Current
KA
Rated Duty Cycle
%
Secondary Voilage
V
Rated Power
KVA
Electrode
Pressure
N
Electrode
Stroke
mm
Cooling Water
Lmim
MD-10T
10
50
≈9.8
≤20
1200
50
20
MD-20
20
50
≈9.8
≤50
4700
80
24
MD-25
25
50
≈9.8
≤70
4700
80
24
MD-40
40
50
≈11.6
≤120
7300
80
30
MD-60
60
50
≈11.6
≤160
12000/18000
100
50
MD-80
80
50
≈11.6
≤240
12000/18000
100
50
MD-120
120
50
≈11.6
≤300
18000
100
60
